Speaker cone paper manufacturing method and speaker cone paper
Slim loudspeakers
A slim type structure in which the diaphragm is sloped in the same shape as the top plate, while the damper is located at the upper side.
Speaker with an internal damper
It is a design structure that simultaneously combines the external and internal parts of the bobbin.
Bass reinforcement speaker
A separate suspension structure is installed in the speaker unit inside the enclosure.
Dome tweeter
It is a design structure in which both the diaphragm and the bobbin are integrally formed.
Loudspeaker
Supplementary Explanation
- Rim-diameter of diaphragm can be grown by free of
inner rim-diameter of diaphragm edge, and vibration
area of diaphragm can be increase, whereby the
sound pressure is increased.
Also, the appearance is simplified, so it is
aesthetically pleasing
Slim Loudspeaker
Supplementary Explanation
- As the upper diaphragm are configured in the form of
a flat it can reduce the thickness of speaker unit,
along with lower part of the diaphragm is installed
under top part of diaphragm, the output power
shall not decrease
Audio playback methods and devices for audio equipment
Supplement Explanation
- High-frequency speaker unit installed on front of
audio equipment, it is possible to reduce size,
due to sound is created in the center part of
Low-frequency speaker, it can be formed what the
listener wants sound image
