BH어쿠스틱

Full Range

BH16M022L Driver Type : Full Range
Size : 68mm (2.6inch)
Magnet : Ferrite

BH16M022L

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 83.0dB ± 2dB (1W/1m)
Nominal Impedance : 8Ω
Free Air Resonance Frequency, fs : 180Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø20.4 (mm)
Net Weight : 350g (12.3oz)
BH14M004-2S Driver Type : Full Range
Size : 65mm (2.6inch)
Magnet : Ferrite

BH14M004-2S

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 82.0dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 225Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 350g (12.3oz)
BH14K039S Driver Type : Full Range
Size : 65mm (2.6inch)
Magnet : Ferrite

BH14K039S

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 78.5dB ± 2dB (1W/1m)
Nominal Impedance : 8Ω
Free Air Resonance Frequency, fs : 170Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø25.4 (mm)
Net Weight : 350g (12.3oz)
13C061 Driver Type : Full Range
Size : 65mm (2.6inch)
Magnet : Ferrite

13C061

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 82dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 220Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 175g (6.2oz)
BH16N003L Driver Type : Full Range
Size : 58mm (2.2inch)
Magnet : Ferrite

BH16N003L

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 76dB ± 2dB (1W/1m)
Nominal Impedance : 8Ω
Free Air Resonance Frequency, fs : 150Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø20.4 (mm)
Net Weight : 275g (9.7oz)
BH16A014L Driver Type : Full Range
Size : 58mm (2.2inch)
Magnet : Ferrite

BH16A014L

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 79dB ± 2dB (1W/1m)
Nominal Impedance : 12Ω
Free Air Resonance Frequency, fs : 130Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø20.4 (mm)
Net Weight : 275g (9.7oz)
BH12L044 Driver Type : Full Range
Size : 58mm (2.2inch)
Magnet : Ferrite

BH12L044

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 80dB ± 2dB (1W/1m)
Nominal Impedance : 8Ω
Free Air Resonance Frequency, fs : 180Hz ± 20%
Frequency Range : fs ~ 15kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 200g (7.1oz)
BH13E029 Driver Type : Full Range
Size : 56mm (2inch)
Magnet : Neodymium

BH13E029

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 86dB ± 2dB (1W/1m)
Nominal Impedance : 16Ω
Free Air Resonance Frequency, fs : 250Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø25.4 (mm)
Net Weight : 107g (3.8oz)
BH16B001 Driver Type : Full Range
Size : 55mm (2inch)
Magnet : Neodymium

BH16B001

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 82dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 175Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 60g (2.1oz)
BH11G055 Driver Type : Full Range
Size : 46*65mm (1.8*2.6inch)
Magnet : Ferrite

BH11G055

Rated Power Handling : 3W (RMS)
Characteristic Sensitivity : 75.5dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 430Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø13.28 (mm)
Net Weight : 53.5g (1.9oz)
BH15N004 Driver Type : Full Range
Size : 45mm (1.8inch)
Magnet : Neodymium

BH15N004

Rated Power Handling : 10W (RMS)
Characteristic Sensitivity : 80.5dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 170Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 45.7g (1.6oz)
BH16K010L Driver Type : Full Range
Size : 40*100mm (1.6*3.9inch)
Magnet : Ferrite

BH16K010L

Rated Power Handling : 5W (RMS)
Characteristic Sensitivity : 81dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 215Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 180g (6.3oz)
BH16M021L Driver Type : Full Range
Size : 40mm (1.6inch)
Magnet : Neodymium

BH16M021L

Rated Power Handling : 3W (RMS)
Characteristic Sensitivity : 76.5dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 180Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 67.5g (2.4oz)
BH14H017L Driver Type : Full Range
Size : 40mm (1.6inch)
Magnet : Neodymium

BH14H017L

Rated Power Handling : 5W (RMS)
Characteristic Sensitivity : 78dB ± 2dB (1W/1m)
Nominal Impedance : 4Ω
Free Air Resonance Frequency, fs : 150Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø16.28 (mm)
Net Weight : 93g (3.2oz)
BH11L028 Driver Type : Mid Range
Size : 34mm (1.3inch)
Magnet : Ferrite

BH11L028

Rated Power Handling : 3W (RMS)
Characteristic Sensitivity : 76.5dB ± 2dB (1W/1m)
Nominal Impedance : 8Ω
Free Air Resonance Frequency, fs : 370Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : Ø13.28 (mm)
Net Weight : 93g (3.2oz)
BH14B015 Driver Type : Mid Range
Size : 25x72mm (1x2.8inch)
Magnet : Neodymium

BH14B015

Rated Power Handling : 5W (RMS)
Characteristic Sensitivity : 79.5dB ± 2dB (1W/1m)
Nominal Impedance : 8Ω
Free Air Resonance Frequency, fs : 230Hz ± 20%
Frequency Range : fs ~ 20kHz ± 20%
Voice Coil Inner Diameter : 15.8*9.56 (mm)
Net Weight : 72g (2.5oz)
